Pipe couplings - Spigot end pipe connectors

Pipe plain end connectors WA - GZ Couplings.

sewer-pipe-spigot-end-connector-couplings
pipe-connector-plain-end-gpz-110-180
pipe-connectors-high-temperature-pipes-gpz-230C

Pipe connectors WA-GZ couplings connect all pipe materials. All pipe sizes from 4" - 96" (100 mm to 2400 mm outside diameter pipes)

WA - GZ unique technology offers multi functional outer clamp bands and an inner clamps on the same unit. The outer clamps insure tightness on the pipe. The inner compression clamp bands maintain pipe alignment, prevents bending at the joint.

Sealing elastomer are EPDM and NBR or Silicone, with 304L stainless steel clamp bands.

Pipe connectors connect "Plain end pipes". The flexible coupling connects full length pipe sections or replacement sections for pipe repairs.

Silicone rubber connector couplings, are suitable for low or high temperature applications. (Silicone -100F to + 450F)

Pipe coupling applications:

  • HDPE, PVC, Steel, PE, Cast Iron and concrete pipes.
  • Special designed with outer bands for tightness inner bands allow axial movement.
  • Stainless steel bands and locks for watertight connections
  • Max. operational pressure 0.5 bar - will vary with pipe size
  • Fits all American and International pipe sizes

READ MORE

Request email quote or call Westatlantic 1-902 455-4455

Pipe Couplings for different diameter pipes

WA-GZ-DS pipe clamp connectors

Connect different sizes pipes - Pipe reducing adapter

sewer-pipe-spigot-connectors-pipe-different-size-diameters
sewer-pipe-spigot-connectors-different-size-pipe

WA-GZ-DS pipe couplings seals, connect of pipes with different size diameters.

A WA-GZ-DS pipe connector couplings accommodate pipe that are not centered or eccentric joints.

All pipe sizes may be accommodated.

Specifications:

  • Diameter range: 100 - 2640 mm (4 inch. to 100 inch. pipe)
  • Maximum operating pressure: gravity feed lines Max 3.62 psi
  • Material steel: Stainless steel
  • Sealing material: EPDM, NBR, SILICONE
  • Working temperature:
  • EPDM (-30 ° C - + 100 ° C)
  • NBR (-20 ° C - + 90 ° C) Silicone up to 230 C

Request email quote or call Westatlantic 1-902 455-4455

sewer-spigot-connectors-for-multipe-pipes

Multi pipe couplings WA-GZ-MC

Multi pipe couplings connect cluster of smaller pipes into a larger pipe.

A WA-GP-MC units seal smaller diameter pipes connecting to a a larger collector pipe.

The smaller pipes may pass through a seal at the pipe end. Using a connector sleeve and seal, multi pipes can drain into a larger pipe at any point along the pipe bore.

Request email quote or call Westatlantic 1-902 455-4455
